Digital Encoding And Decoding
by George Benthien

2018

Many electronic communication devices today process and transfer information digitally. Examples are cable televisions, cell phones, cable/DSL modems, and wireless routers. Digital information is specified by a sequence of zeroes and ones... more
Figure 7: Amplitude modulated signal corresponding to the bit sequence (101110).
Figure 8: Frequency modulated signal corresponding to the bit sequence (101110). two transmission frequencies. The one having the largest output over a symbol period corresponds to the frequency used in that symbol period. 3.3. Continuous Phase FSK Modulation (CPFSK) A continuous phase FSK signal has the form
Figure 4: An example of a Manchester encoded signal.
where d7(t) and dg(t) are the same digital signals used previously. The functions d; and dg are continuous at odd multiples of 7’, and sin( $f) is zero at even multiples of 7’. Therefore, the second term on the right-hand-side of equation (10) is continuous. Since cos( 3 +) vanishes at odc 2T multiples of T, the signal x(t) will be continuous if we can modify d7(t) so that it is continuous at even multiples of T. This is easily done. We only need to shift d;(t) to the left by T as i: illustrated in Figure 12. With this modification x(t) is called an MSK signal. We will now show that the MSK signal x(t) is in fact a continuous phase FSK signal.
.6 Quadrature Amplitude Modulation (QAM) Amplitude and phase modulation are often combined. In Quadrature Amplitude Modulation (QAM, the signal has the form
One of the most popular forms of phase modulation is Quadrature Phase Shift Keying (QPSK). In QPSK the phase ¢(t) takes on one of the four values 21/4, 32/4, 52/4, or 77/4 in each symbol period. The signals corresponding to these four phase angles are A[cos(2z fet) —sin(22 fet) | /V2, A[—cos(2x fet) — sin(2xfet)|//2, A[—cos(2x fet) + sin(2xfet)]/V/2, and A[cos(2z fet) + sin(2x fet) |/V2. If we let A = V2, then the pair (J, Q) takes on the values (1,—1), (—1,—1), (—1, 1), and (1, 1). Each signal x(t) corresponds to a unique pair (J, Q). Figure 9 shows the points corresponding to the pairs (J, Q) for QPSK along with the associated symbols. Figure 9: Constellation diagram for QPSK modulation.
Table 1: Four bit to five bit conversion table. The five bit codes were selected so that there is no more than one leading zero and no more than two trailing zeros. Thus, when the codes are strung together, there can be no more than three consecutive zeros. The string of bits after the replacement are transmitted using NRZI. As we saw before, NRZI effectively handles strings of ones. An example of a 4B/5B encoded signal is shown in Figure 5.
Figure 16: Diagram showing the steps in Orthogonal Frequency Division Multiplexing. with the PSK and QAM modulation schemes can be looked upon as defining mappings between symbols and complex values. Using one of the constellation diagrams we assign the complex number corresponding to the first symbol to Xo, the complex number corresponding to the second symbol to X;, and so on until the complex number corresponding to the N-th symbol is assigned to Xy-_1. We then obtain a sequence of time values {x,,} by means of the inverse DFT defined in equation (32). This sequence is in general complex. The real and imaginary parts of this sequence can be converted to continuous functions of time on the interval 7 using a digital-to- analog converter (DAC). The real and imaginary functions of time on each symbol period are often used to modulate carrier signals cos(27 f-t) and sin(2z f-t) respectively. A diagram of the process is shown in Figure 16.
The simplest digital signal representing a bit sequence uses just two voltage levels and represents a 1 by the higher voltage and a zero by the lower voltage. This type of encoding is called NRZ (Non-Return to Zero). An example of an NRZ encoded signal is shown in Figure 1. Although simple, this method for encoding digital information has some serious drawbacks and is seldom used. First, it is difficult to keep the clocks of the source and receiver synchronized if there happen to be long sequences of ones or zeros. The receiver uses transitions in level to determine clock cycle boundaries. Second, it is impossible to distinguish between a long sequence of zeros and the absence of a signal. Third, a long series of zeros or ones causes the average signal value, which is used to distinguish between high and low values, to drift. Thus, for many reasons, it is desirable to have frequent transitions between the high and low values.
Figure 15: Constellation diagram for 16-QAM modulation. QAM signals can be demodulated using a coherent scheme like that used for phase shift keying. Multiplying the signal s(t) by cos(2z f-t) and using trigonometric formulas for double angles, we get
Figure 2: Example of NRZI encoding.
In Manchester encoding 0 and | bits are represented in a clock cycle by the signals shown in Figure 3.
Figure 6: An example of MLT-3 encoding.
Figure 13: Smooth FSK signal corresponding to the bit sequence (101110). By adding and subtracting equations (18a) and (18b) we obtain
frequency limit of an MLT-3 signal will be about one-fourth that of a Manchester encoded signal. In Fast Ethernet (100 Mbps) MLT-3 is applied to the signal generated by 4B/5B and NRZI. Higher order block codes such as 8B/10B and higher order multi-level methods such as MLT-5 are used in higher speed Ethernet networks.
to represent 3 bits per symbol. This modulation scheme is called 8-PSK.
Figure 17: Example of Direct Sequence Spread Spectrum. The signal d(t) must be known by both the transmitter and receiver. Often the pattern of plus and minus ones in d(t) is generated by an algorithm based on some shared seed. The signal s(t) has a noise-like appearance and thus provides some protection against eavesdropping. Figure 17 shows an example of the various signals that make up a DSSS signal.
Figure 11: Constellation diagram for 8-PSK modulation. some systems use a modification of phase shift keying called Differential Phase Shift Keying DPSK). Instead of using phase angles relative to a fixed standard, DPSK uses phase angles relative o the phase in the preceding symbol period. DPSK is simpler to implement than ordinary PSK, out has larger demodulation errors.
