SAR tomography

DLR's Microwave and Radar Institute has been operating the F-SAR airborne SAR instrument since 2007. This contribution presents first the SAR imaging capabilities of the system followed by a discussion on recent developments in SAR signal processing using F-SAR data acquired in diverse special modes, each suitable for a specific application: large baseline, dual-frequency SAR interferometry for precise DEM generation, high resolution circular SAR imaging, advanced filtering and polarimetric change detection. The paper concludes with an outlook on future developments.

I We show the result ontained with SVD inversion using the real data. Finally, we combine the SVD optimisation of the constellation with the parametric inversione in the case of real data and reduced constellation. Conclusions and outlook are carried out at the end of the chapter. V VI Contents 3.3.1 Global Optimisation of objective function . . . . . . . 4 3D Reconstruction: numerical and experimental results 4.1 Simulated data analysis .

The SARTOM project addresses a key area of defence interest, namely the detection and identification of targets hidden in foliage. The project has provided a rich source of data obtained from a series of flight trials that were conducted in September 2006 at the test site Dornstetten, west of Munich, Germany. This multi-frequency (X-, C-and L-Band) and fully polarimetric data set is being examined with the use of advanced processing techniques designed to extract the maximum amount of information contained in the data: namely SAR Tomography and the analysis of multi-polarimetric and multi-frequency scattering characteristics of the foliage and target signatures. In supporting work a foliage radar penetration simulation model (PRIS) is being used to assess the detection and classification capabilities of different radar configurations applied to targets beneath foliage. In this paper results are presented derived from the experimental data and from the simulation model.

This paper describes BorealScat, a tower-based radar campaign for acquiring multitemporal polarimetric, tomographic and Doppler radar measurements at P-, Land C-band over a hemi-boreal forest site in Remningstorp, Sweden. The facility consists of a 50-m high tower equipped with a radar system including an array of 30 antennas. The site will also be equipped with meteorological instruments and moisture sensors. The aim of the experiment is the temporal survey of radar signatures over time scales ranging from sub-seconds to years in varying environmental conditions. This experiment will provide fundamental information about the electromagnetic scattering mechanisms in boreal forests at P-, Land C-band.

This paper presents new experimental results of 3-D imaging using tomographic techniques over a snow covered sea ice medium, sensed with an X-band radar system. The available data are from a ground-based synthetic aperture radar data collection campaign carried out over Kattfjord, Tromsø, Norway. Direct imaging of the vertical structures of the radar reflectivity of the snow and sea ice layers is achieved by focusing the signal from a 2-D synthetic array in the 3-D space. The effect of a change in propagation velocity of the wave inside the considered medium is investigated in the focusing process, and the tomograms are effectively corrected for this effect. The distribution of the scattering contributions in the vertical direction reveals a strong response from the sea ice cover. Tomograms at two different polarizations are investigated and compared. The results and the interpretations are also supported by the simulated data from the same system.

A lot of research and development has been devoted to the exploitation of satellite SAR images for deformation measurement and monitoring purposes since Differential Interferometric Synthetic Apertura Radar (InSAR) was first described in 1989. In this work, we consider two main classes of advanced DInSAR techniques: Persistent Scatterer Interferometry and Tomographic SAR. Both techniques make use of multiple SAR images acquired over the same site and advanced procedures to separate the deformation component from the other phase components, such as the residual topographic component, the atmospheric component, the thermal expansion component and the phase noise. TomoSAR offers the advantage of detecting either single scatterers presenting stable proprieties over time (Persistent Scatterers) and multiple scatterers interfering within the same range-azimuth resolution cell, a significant improvement for urban areas monitoring. This paper addresses a preliminary inter-comparison of the results of both techniques, for a test site located in the metropolitan area of Barcelona (Spain), where interferometric Sentinel-1 data were analysed.

Spatially variant apodization (SVA) is a nonlinear sidelobe reduction technique that improves sidelobe level and preserves resolution at the same time. This method implements a bidimensional finite impulse response filter with adaptive taps depending on image information. Some papers that have been previously published analyze SVA at the Nyquist rate or at higher rates focused on strip synthetic aperture radar (SAR). This paper shows that traditional SVA techniques are useless when the sensor operates with a squint angle. The reasons for this behaviour are analyzed, and a new implementation that largely improves the results is presented. The algorithm is applied to simulated SAR images in order to demonstrate the good quality achieved along with efficient computation.

Synthetic aperture radar (SAR) tomography is a 3-D imaging modality that is commonly tackled by spectral estimation techniques. Thus, the backscattered power along the cross-range direction can be readily obtained by computing the Fourier spectrum of a stack of multibaseline measurements. In addition, recent work has addressed the tomographic inversion under the framework of compressed sensing, thereby recovering sparse cross-range profiles from a reduced set of measurements. This paper differs from previous publications, in that it focuses on sparse expansions in the wavelet domain while working with the second-order statistics of the corresponding multibaseline measurements. In this regard, we elaborate on the conditions under which this perspective is applicable to forested areas and discuss the possibility of optimizing the acquisition geometry. Finally, we compare this approach with traditional nonparametric ones and validate it by using fully polarimetric L-band data acquired by the Experimental SAR (E-SAR) sensor of the German Aerospace Center (DLR).

Super-resolution concepts offer the potential of resolution beyond the classical limit. This great promise has not generally been realised. The potential application of super-resolution concepts to synthetic aperture radar is investigated. The analytical basis for super-resolution theory is discussed. The application of the concept to synthetic aperture radar is investigated as an operator inversion problem. Generally, the operator inversion problem is ill posed. However, it is shown that it is the particular form of the eigenvalue spectrum of the associated operator that precludes any significant resolution enhancement of synthetic aperture radar images. A criterion for judging super-resolution processing of an image is presented.

Estimates of the magnitude and distribution of aboveground carbon in Earth's forests remain uncertain, yet knowledge of forest carbon content at a global scale is critical for forest management in support of climate mitigation. In light of this knowledge gap, several upcoming spaceborne missions aim to map forest aboveground biomass, and many new biomass products are expected from these datasets. As these new missions host different technologies, each with relative strengths and weaknesses for biomass retrieval, as well as different spatial resolutions, consistently comparing or combining biomass estimates from these new datasets will be challenging. This paper presents a demonstration of an inter-comparison of biomass estimates from simulations of three NASA missions (GEDI, ICESat-2 and NISAR) over Sonoma county in California, USA. We use a high resolution, locally calibrated airborne lidar map as our reference dataset, and emphasize the importance of considering uncertainties in both reference maps and spaceborne estimates when conducting biomass product validation. GEDI and ICESat-2 were simulated from airborne lidar point clouds, while UAVSAR's L-band backscatter was used as a proxy for NISAR. To estimate biomass for the lidar missions we used GEDI's footprint-level biomass algorithms, and also adapted these for application to ICESat-2. For UAVSAR, we developed a locally trained biomass model, calibrated against the ALS reference map. Each mission simulation was evaluated in comparison to the local reference map at its native product resolution (25 m, 100 m transect, and 1 ha) yielding RMSEs of 57%, 75%, and 89% for GEDI, NISAR, and ICESat-2 respectively. RMSE values increased for GEDI's power beam during simulated daytime conditions (64%), coverage beam during nighttime conditions (72%), and coverage beam daytime conditions (87%). We also test the application of GEDI's biomass modeling framework for estimation of biomass from ICESat-2, and find that ICESat-2 yields reasonable biomass estimates, particularly in relatively short, open canopies. Results suggest that while all three missions will produce datasets useful for biomass mapping, tall, dense canopies such as those found in Sonoma County present the greatest challenges for all three missions, while steep slopes also prove challenging for single-date SAR-based biomass retrievals. Our methods provide guidance for the inter-comparison and validation of spaceborne biomass estimates through the use of airborne lidar reference maps, and could be repeated with on-orbit estimates in any area with high quality field plot and ALS data. These methods allow for regional interpretations and filtering of multi-mission biomass estimates toward improved wall-to-wall biomass maps through data fusion.

Our study aims to provide a comparison of the P- and L-band TomoSAR profiles, Land Vegetation and Ice Sensor (LVIS), and discrete return LiDAR to assess the ability for TomoSAR to monitor and estimate the tropical forest structure parameters for enhanced forest management and to support biomass missions. The comparison relies on the unique UAVSAR Jet propulsion Laboratory (JPL)/NASA L-band data, P-band data acquired by ONERA airborne system (SETHI), Small Footprint LiDAR (SFL), and NASA Land, Vegetation and Ice Sensor (LVIS) LiDAR datasets acquired in 2015 and 2016 in the frame of the AfriSAR campaign. Prior to multi-baseline data processing, a phase residual correction methodology based on phase calibration via phase center double localization has been implemented to improve the phase measurements and compensate for the phase perturbations, and disturbances originated from uncertainties in allocating flight trajectories. First, the vertical structure was estimated from L- and P-ban...

Estimates of the magnitude and distribution of aboveground carbon in Earth's forests remain uncertain, yet knowledge of forest carbon content at a global scale is critical for forest management in support of climate mitigation. In light of this knowledge gap, several upcoming spaceborne missions aim to map forest aboveground biomass, and many new biomass products are expected from these datasets. As these new missions host different technologies, each with relative strengths and weaknesses for biomass retrieval, as well as different spatial resolutions, consistently comparing or combining biomass estimates from these new datasets will be challenging. This paper presents a demonstration of an inter-comparison of biomass estimates from simulations of three NASA missions (GEDI, ICESat-2 and NISAR) over Sonoma county in California, USA. We use a high resolution, locally calibrated airborne lidar map as our reference dataset, and emphasize the importance of considering uncertainties in both reference maps and spaceborne estimates when conducting biomass product validation. GEDI and ICESat-2 were simulated from airborne lidar point clouds, while UAVSAR's L-band backscatter was used as a proxy for NISAR. To estimate biomass for the lidar missions we used GEDI's footprint-level biomass algorithms, and also adapted these for application to ICESat-2. For UAVSAR, we developed a locally trained biomass model, calibrated against the ALS reference map. Each mission simulation was evaluated in comparison to the local reference map at its native product resolution (25 m, 100 m transect, and 1 ha) yielding RMSEs of 57%, 75%, and 89% for GEDI, NISAR, and ICESat-2 respectively. RMSE values increased for GEDI's power beam during simulated daytime conditions (64%), coverage beam during nighttime conditions (72%), and coverage beam daytime conditions (87%). We also test the application of GEDI's biomass modeling framework for estimation of biomass from ICESat-2, and find that ICESat-2 yields reasonable biomass estimates, particularly in relatively short, open canopies. Results suggest that while all three missions will produce datasets useful for biomass mapping, tall, dense canopies such as those found in Sonoma County present the greatest challenges for all three missions, while steep slopes also prove challenging for single-date SAR-based biomass retrievals. Our methods provide guidance for the inter-comparison and validation of spaceborne biomass estimates through the use of airborne lidar reference maps, and could be repeated with on-orbit estimates in any area with high quality field plot and ALS data. These methods allow for regional interpretations and filtering of multi-mission biomass estimates toward improved wall-to-wall biomass maps through data fusion.

A problem with synthetic aperture radar (SAR) is that, due to the poor penetrating action of electromagnetic waves inside solid bodies, the capability to observe inside distributed targets is precluded. Under these conditions, imaging action is provided only on the surface of distributed targets. The present work describes an imaging method based on the analysis of micro-movements on the Khnum-Khufu Pyramid, which are usually generated by background seismic waves. The results obtained prove to be very promising, as high-resolution full 3D tomographic imaging of the pyramid's interior and subsurface was achieved. Khnum-Khufu becomes transparent like a crystal when observed in the micro-movement domain. Based on this novelty, we have completely reconstructed internal objects, observing and measuring structures that have never been discovered before. The experimental results are estimated by processing series of SAR images from the second-generation Italian COSMO-SkyMed satellite s...
